Model

Parameters

AE-IPC50AZ60-20E9-0604-P2

Imaging Sensor

1/2.7" SC2235 CMOS

Chipset

MSC313E

Effective Pixels

2MP

Minimum Illumination

Color：0.001Lux@F1.2；B&W：0Lux@F1.2（IR on）

IR Distance

20-30M（2 x IR III IR Lamp）

Lens

4mm fixed aperture lens (2.8, 6,8mm optional)

Lens Interface Type

M12

Noise Reduction

3D digital noise reduction

WDR

Supports Digital Wide Dynamic (D-WDR)

BLC

Support

S/N Ratio

≥50db (AGC closed)

Image Settings

Supports brightness, contrast, saturation, white balance, AWB (automatic white balance), AGC (automatic gain), AE (automatic exposure); support privacy zone; normal/90°/270° image rotation; automatic, manual color to black and other kinds of switching

Audio And Video Coding

Encoding Format

H.265 Main Profile encoding；

H.264 Baseline/ Main Profile/High Profile encoding

Main Stream Resolution

1920×1080，1-20fps,；

Sub stream Resolution

704×576，1-20fps,；

640×480，1-20fps,；

Video Bit Rate

32Kbps-8Mbps continuously adjustable, supporting CBR/VBR

Character Overlay

Support overlay for channel name, date and time, stream information and position is adjustable

Audio Encoding

G.711

Audio Bit Rate

64Kbps

Intelligent Analysis

Intelligent Analysis

Target count, object left/lost, area detection, line crossing;

Internet Function

Alarm Mechanism

FTP、E-mail、Browser, Management software

Supporting Agreement

TCP/IP, DHCP, HTTP, HTTPS NTP, DNS, RTP RTSP

Interface Protocol

ONVIF

Communication Interface

1 x RJ45 10M / 100M Adaptive Ethernet port

General Specification

Operation

-20°C ~ 55°C/0﹪-90﹪

Power Supply

POE

Power Consumption (Max)

<10W

Water Resistance Level

IP66

Size (Mm)

Device：71(W)×58.1(H)×110 (L)mm；
